Type K Diopter Sight manual
Translated from French

Swiss Diopters on the firing line

Front Cover

The front sight uses replaceable inserts. The inserts can be of the post or peep variety. The rear sight has an adjustable aperture. Diopter sights are extremely difficult to come by in the states. They can be ordered from gunstores in Switzerland, but are quite expensive. Expect to pay at least $225 plus shipping. Yard target clearly, with my fron sight still in focus. It hasn't added to my score, but it means I can maintain my scores as my eyes age. I just got mine this Spring, and although a 1/4 diopter lens makes the target look REALLY sharp, I haven't had time to see if it's beginning to interfere with my ability to focus on my front sight. 'filed' Swedish diopter sights I've got two sets of Elit diopter sights for a Swedish Mauser. One looks like it has been ground or filed on the mounting surface to fit the rear bridge of the rifle, while one is 'pristine', with several ridges on the bottom.

ContentsPage
Description 2-3
Characteristics Techniques 2-3
Front Sight Installation 4-5
Rear Sight Installation 6-7
Adjusting the Line of Sight 8-9
Aiming 10
Parts List (not translated) 11-15

Description; The type K diopter plus front sight is a aiming system that can be mounted on any K31 without any modification to the weapon.
Technical characteristics;
The diopter is adjustable for distances of 50m to 600m. It comes with an eyepiece with a perforated disc that has six sighting holes for the convenience of the shooter and measuring, respectively; 1,0mm, 1,2mm, 1,4mm, 1,6mm, 1,8mm, 2,0mm.
Windage and elevation adjustments are made with two adjustment screws. The elevation screw should be adjusted in the following manner;
shot too high-turn elevation screw clockwise
shot too low - ' ' ' counter-clockwise
windage adjustment;
shot to left- turn adjuster to the right
shot to right- turn adjuster to the left
The adjustment screws for both elevation and windage are furnished with click stop graduated lines that represent 2 centimeters each at 300meters distance.
The sight line distance is 760mm.

(Pages 2-3)

Mounting the front sight;
-back off the mounting bolt (27) until the threads are no longer visible.
-with arrow (26) pointing towards target, slide the front sight assy. over the rifle's fixed sight until it seats
-firmly press down on the front sight barrel while while tightening the set screw (29).
- check for play in all directions (there should be none).
(Pages 4-5)

Diopter Sights Ar15

Mounting the diopter (rear sight);
-Unscrew (without forcing) the knurled mounting screw (9).
-using your left hand, set the diopter assembly in place onto the receiver with the forward leg (7) set on the wide part of the ejection port (8)and the eyepiece just on top of the rear of the receiver.
-hand tighten to set screw, then finish tightening with the factory tool.
Warriors orochi 2 pc download utorrent. -hand check for play in all directions (there should be none).

(Pages 6-7)

Adjusting the line of sight;
-Once in place on the receiver, make sure that the eyepiece is centered in windage (24) and elevation (25) by looking at the long white reference lines (C&D) (opposite of the side you aim through).
-next, set your factory front sight in position 10, representing 1000 meters. Now look through the diopter and line everything up on the target. The sight picture should be perfectly concentric and tangent.

(Pages 8-9)

Aiming process:

Align the front tunnel and rear tunnel to give a concentric sight picture, where the target appears just above the front sight post.

(Page 10)
